Wiper

<?xml version="1.0" standalone="yes"?>

Windscreen washer, wiper

Vehicle fitted with intermittent windscreen wipers


Chapter

Audible and visual signals

<?xml version="1.0" standalone="yes"?>

Horn


Press the steering wheel boss A to sound the horn.

Headlight flasher

To flash the headlights, pull the stalk 1 towards you, then release.

Chapter

Headlight beam adjustment

<?xml version="1.0" standalone="yes"?>

Switch A is used to adjust the height of the headlight beams according to the load.

With the dipped beam headlights on, press or raise switch A as many times as required to select the required position on the instrument panel.

Chapter

Steering

<?xml version="1.0" standalone="yes"?>

Adjusting the steering wheel height and depth


Lower the lever 1 and set the steering wheel to the required position.

Then, raise the lever fully, beyond the point of resistance to lock the steering wheel.

Chapter

Warning lights

<?xml version="1.0" standalone="yes"?>

The presence and operation of the warning lights VARY ACCORDING TO THE EQUIPMENT AND COUNTRY.

warning

If no lights or sounds are apparent, this indicates a fault in the instrument panel. This indicates that it is essential to stop immediately (as soon as traffic conditions allow). Ensure that the vehicle is correctly immobilised and contact an approved Dealer.

Chapter

Clock and outdoor temperature

<?xml version="1.0" standalone="yes"?>

From the multimedia screen

The time and outdoor temperature are displayed on the multimedia screen 1.

Refer to the multimedia instructions.

Exterior temperature indicator

Special feature:

When the exterior temperature is between -3°C and +3°C, the °C characters flash to signal a risk of ice on the road.

Chapter

Vehicle settings personalisation menu

<?xml version="1.0" standalone="yes"?>

Depending on the vehicle equipment, this function allows you to activate/deactivate and adjust some of the vehicle's functions.

From the multimedia screen 1


Chapter
